6Volt regulator
6Volt regulator, TO-92 LM7806
Category
Subcategory
EDD - Discrete Semiconductor: Diodes, Transistors, LDR, LED
Description
LM7806 TO-92 voltage regulator device designed to provide stable 6V DC output for electronic circuits, embedded systems, sensors, and low-power applications.
It regulates higher input voltage into a constant 6V output with built-in thermal overload and short-circuit protection for reliable and safe operation. Commonly used in Arduino projects, battery-powered systems, robotics circuits, educational electronics kits, and embedded development applications.
Manufacturer Details
| Manufacturer | Part Number |
|---|---|
| Texas Instruments | LM7806CT |
| STMicroelectronics | L7806CV |
| ON Semiconductor | MC7806ACTG |
| Fairchild Semiconductor | KA7806 |
Vendor Suppliers
Application Resources
No application resources.
Technical Specifications
| Device Type | Linear Voltage Regulator |
| Output Voltage | 6V DC |
| Package Type | TO-92 |
| Input Voltage Range | 8V – 20V |
| Output Current | Up to 100mA |
