Force Sensor - SQUARE

Force Sensitive Resistor Square Sensor

Subcategory
EMS - Input: Sensors

Description

This is a force sensitive resistor with a square, 1.75 x 1.5″, sensing area. This FSR will vary its resistance depending on how much pressure is being applied to the sensing area. The harder the force, the lower the resistance. When no pressure is being applied to the FSR its resistance will be larger than 1MΩ. This FSR can sense applied force anywhere in the range of 100g-10kg. Just Connect a resistor to form a voltage divider and measure the voltage at the junction to find the force applied. These sensors are simple to set up and great for sensing pressure, but they aren’t incredibly accurate. This sensor can be easily interfaced with Microcontrollers, Arduino Boards, Raspberry Pi, etc. using an Analog to Digital Converter (ADC).

Manufacturer Details

Manufacturer Part Number
Interlink Electronics FSR 406
SparkFun Electronics SEN-09376
DFRobot SEN0206
Adafruit Industries CFR25J220R1075
Ohmite FSR07CE

Application Resources

force-sensitive-resistor

Technical Specifications

Actuation Force 0.1 N
Clock Speed 16MHz
